DRT2-ID32ML
Omron has developed a MIL connector terminal with transistor with 32 input channels called the DRT2-ID32ML. It facilitates coordination between various automation components, such as PLCs, HMIs, and sensors. It has a sturdy IP67 casing, so it works dependably between -25 and 70 degrees Celsius. Automatic baud rate adjustment and rotary switches for node address settings are just two of the ways the Smart Slave streamlines configuration and boosts equipment efficiency.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for DRT2-ID32ML
| Manufacturer | Omron |
|---|---|
| Product Type | MIL Connector Terminal |
| Product Line | DRT |
| Part Number | DRT2-ID32ML |
| Weight | 0.25 lbs (0.11 kg) |
| Series | DRT2 |
| Connector Type | NPN connector |
| Number of Channels | 32-channel |
| Safety Standards | RoHS, UL listed |
| Current Consumption | 55 mA max. (24 V DC), 100 mA max. (11 V DC) |
| Power | 24 VDC |
| IP Rating | IP67 |
| Operating Temperature | -25 to 70 degrees Celsius |
| Communication Protocol | DeviceNet |
| Configuration Interface | Rotary switches, Configurator |
The Omron DRT2-ID32ML is a 32-channel MIL connector terminal with basic input capabilities for ON/OFF signals that are intended to speed up the operation of equipment. It belongs to the Omron DRT2 family, which complies with international safety norms like ISO and IEC to provide dependability and compliance in safety-critical applications. Because of its modular construction, the connector terminal may be readily expanded and customized to satisfy various safety needs. It works with Omron automation products including PLCs, HMIs, and sensors, and can connect up to 32 input or output devices to a single PLC or HMI. DeviceNet, a communication protocol developed by Omron, is used by the connector terminal to maintain constant contact. Performance in a variety of situations is ensured by its durable housing, which has an IP67 classification to guard against dust and water ingress. The connecter terminal has an ON voltage of 17 VDC minimum and an OFF voltage of 5 VDC with an OFF current of 1 mA maximum. UL listing and RoHS compliance are both features of the connection, which can handle 55 mA of current at 24 volts of DC power and 100 mA of current at 11 volts of DC power. Due to its small size (130 mm x 40 mm x 20 mm) and lightweight (0.12 kg), it may be used in a variety of applications, including robotics, industrial automation, machine control, and process control. With its automated baud rate modification, the terminal does not require human configuration, and its rotary switches make it easy to set up clear node addresses. Enhancing user settings and monitoring capabilities, it provides extra status information allocation in the Master's IN Area. Overall, the DRT2-ID32ML channel MIL connector is an effective and reasonably priced industrial automation solution that enables smooth communication and boosts equipment performance.
