Product image is representative; revision or series may vary. Contact us to request a specific version.
TSXDSY08S5
The TSXDSY08S5 from Schneider Electric is a discrete output module equipped with 8 outputs. It accommodates AC voltage ratings from 120 to 240 V and connects via a screw terminal block.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for TSXDSY08S5
| Manufacturer | Schneider Electric |
|---|---|
| Product Line | Modicon |
| Part Number | TSXDSY08S5 |
| EAN | 3389110725827 |
| Weight | 1.06 lbs (0.48 kg) |
| Product | Discrete Output Module |
| Number of Outputs | 8 |
| Minimum Voltage Rating | 120 V |
| Maximum Voltage Rating | 240 V |
| Voltage Type | AC |
| Electrical Connections | Screw Terminal Block |
| Maximum Ambient Temperature | 60 degrees Celsius |
| Minimum Ambient Temperature | 0 degrees Celsius |
| Operating Humidity Rating | 80% RH (non-condensing) |
| Storage Humidity Rating | 80% RH (non-condensing) |
| Maximum Operating Altitude Without Derating | 1000m above sea level |
The Schneider Electric TSXDSY08S5 is designed as a discrete output module suited for various control tasks. This module features a total of 8 outputs, allowing for comprehensive control in automation systems. It supports AC voltage ranging from 120 volts minimum to a maximum of 240 volts, ensuring compatibility with numerous industrial setups. The unit connects through a screw terminal block for reliable electrical connectivity.
The module's physical dimensions are 18 cm in width, 26 cm in height, and 5.5 cm in depth, with a total weight of approximately 1.05 lbs. This makes it manageable for installation within control panels or related enclosures. Temperature tolerances for operation extend from 0 to 60 degrees Celsius, enabling its use in diverse environments. Furthermore, the device is rated for humidity levels up to 80% relative humidity, both during operation and storage, without the risk of condensation affecting its performance.
In terms of installation flexibility, the TSXDSY08S5 can operate at altitudes of up to 1000 meters above sea level without experiencing derating. This characteristic is essential for applications in varying geographical locations. Overall, Schneider Electric's TSXDSY08S5 discrete output module is an effective choice for reliable electrical distribution in various control applications.
