TSXASY410

The TSXASY410 module from Schneider Electric fits into the TSX Micro PLCs range. It measures 125 mm in width, 100 mm in height, and 40 mm in depth. At just 200 grams, this unit is lightweight yet durable, designed for operational stability in diverse environments.

This component can function effectively in settings with a humidity level of 5% to 95%, free from condensation. It can withstand storage temperatures down to -40°C and operates from 0°C to 60°C during use. Powering the device requires a 24 V DC supply, ensuring efficient operation with a low power consumption of only 3 W.

The TSXASY410 boasts a rapid response time of 1 millisecond per channel, which is suitable for applications that require immediate feedback. It provides four analog output channels, with a minimum load impedance of 2 kΩ for voltage output and a maximum of 500 Ω for current output. Users can expect a current output range of 0 to 20 mA and a voltage output range of 0 to 10 V from this module.

Designed for precision, it maintains an accuracy of ±0.2% of full scale coupled with a resolution of 12 bits. The flexibility in output type allows it to cater to various applications, whether voltage or current output is needed. Overall, the TSXASY410 is designed for high-performance tasks in automation, ensuring measurement reliability and precision.
