Siemens SIMATIC 6ES7151-1BA02-0AB0

Product image is representative; revision or series may vary. Contact us to request a specific version.

6ES7151-1BA02-0AB0

|
Need a Specific Revision?

The Siemens 6ES7151-1BA02-0AB0 is an interface module belonging to the SIMATIC series. This module operates in isochronous mode and typically consumes 3.3 Watts of power during operation. It has a maximum input/output capacity of 64 points.

Out of stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6ES7151-1BA02-0AB0

ManufacturerSiemens
Product TypeInterface Module
Product LineSIMATIC
Part Number6ES7151-1BA02-0AB0
UPC662643223552
Weight0.06 lbs (0.03 kg)
Operating ModesIsochronous mode
Power Loss3.3 Watts (typical)
Ambient Operating Temperature0 to 60°C (in a non-condensing environment)
Input Current Rating200 milliamperes
Communication ProtocolsPROFIBUS DP and PROFINET IO
Physical InterfaceRS-485 serial port
Transmission Rate For The Serial Port12 megabits per second
Rated Supply Voltage24 Volts DC
Status Indicator TypeLED indicators
Input/Output Addressing Volume244 bytes for both input and output
Number of Inputs/Outputs64 inputs/outputs (maximum)
Connector Type9-pin D-SUB connector
Protection RatingIP20
Request a Repair

Siemens designed the 6ES7151-1BA02-0AB0 interface module as a part of the SIMATIC series. It functions within isochronous mode, which allows for precise timing in control applications. The module is rated for a power loss of only 3.3 Watts, making it energy efficient. Operating within temperatures ranging from 0 to 60°C, it is suited for various environments that do not involve condensation.

Weighing 0.33 pounds, or 0.15 kilograms, this module has a low profile that makes installation straightforward. It draws an input current of 200 milliamperes, ensuring compatibility with most control systems. The device supports key communication protocols, including PROFIBUS DP and PROFINET IO, facilitating efficient data transfer and device connectivity.

The physical interface utilizes an RS-485 serial port capable of transmitting data at a speed of 12 megabits per second. This makes it suitable for applications requiring swift communication. The module accommodates a total input/output addressing volume of 244 bytes, allowing expansion within control systems. A 9-pin D-SUB connector provides a reliable interface for connections.

Status indicators are visible via LED lights, showing operational feedback. The 6ES7151-1BA02-0AB0 also has an IP20 rating, indicating it should be installed in environments where it is protected from dust and other particulates but not necessarily against water ingress. This module is an essential component for automated processes, providing flexible and robust interface solutions.
