The 1395 spare parts are spare parts or renewal parts for Allen-Bradley 1395 series digital DC drives. This product line includes spare parts for current-rated 1395 drives and Horsepower-rated 1395 drives. The 1395 spare parts product line includes main control boards, adapter boards, fuses, transformers, front covers, and auxiliary contacts. Some 1395 spare parts are only compatible with 1395 drives that have specific voltage ratings and output power ratings, and other 1395 spare parts are compatible with drives with different voltage and output power ratings.
Browse available units in our catalog of 1395 Spare Parts.
This snubber board supports an input voltage range of 330 to 480 VAC and is effective at operating frequencies between 47 Hz and 63 Hz. It is engineered to function effectively in temperatures reachin
This feedback board is designed for use with 1395 digital DC drives. It operates at a frequency of 50 to 60 Hertz and is compliant with UL and CSA standards. The unit can function at altitudes up to 1
This unit features DC rated contacts, comprising 1 normally closed and 2 normally open contacts. Built to withstand an interrupting capacity of 180 A at 550 VDC, it operates effectively at coil voltag
This module accepts a single-ended electrical input signal of 0 to 5 volts and produces a differential electrical output signal of the same range. With an input impedance exceeding 100,000 ohms, this
This programming terminal is equipped with an LCD display capable of showing 64 characters in a format of 4 lines by 16 characters. It connects via a D-sub 9-pin connector and operates on a power supp
Designed for use as a spare part, this power supply kit is compatible with 1395 DC drives and is field-replaceable for convenience. It supports parameters for setup and configuration, with programming
Designed for durability, this programming terminal withstands shock levels of up to 15 g for 11 milliseconds. It incorporates a membrane keypad with 24 keys for user interaction and displays informati
This main control board features an operating temperature range from 0 °C to approximately 50 °C and a storage temperature range between -40 °C and 85 °C. It can handle humidity levels from 5% to 95%
This multi-communication adapter board interfaces various communication types, including Ethernet to DH+, RIO block transfer, and serial communication to DH+. It supports motor horsepower from 2 to 60
This adapter board features a power rating of 20 HP and operates with a field voltage of 240 VAC. It also has a maximum field current rating of 10:00 AM. The nominal digital I/O voltage is 24 VDC, wit
The 1395 Spare Parts have been designed and manufactured by Allen-Bradley. These parts are also called renewal parts and they are used with Allen-Bradley 1395 drives. Before ordering or using the 1395 Spare Parts, several series levels must be considered. The available series include Series A and Series B (MKVA), and Series A (HKVA). Part of the differentiating features among these series include the voltage and current ratings. For instance, Series A (MKVA) has a voltage rating of between 230 Volts and 460 Volts and a current of 345 Amps while Series A (HKVA) has a voltage rating of 230, 380, or 415 Volts and a current rating of 2250 Amps. The Allen-Bradley 1395 Spare Parts support both current-rated and Horsepower-rated drives. To establish whether a drive is current or Horsepower-rated, the specifications on the drive’s nameplate should be consulted. If the drive contains an extra power output rating entry at the bottom of the label, it is a Horsepower-rated drive.
The Horsepower-sized accessories in the Allen-Bradley 1395 Spare Parts series include parts for the standard 230 to 460 Volts AC Series A drives with ratings from 40 to 200 Horsepower, 230 to 460 Volts AC standard Series B drives with ratings from 1 to 75 Horsepower, and 230 to 460 Volts AC Medium KVA Series B drives with ratings from 12 to 600 Horsepower. The Allen-Bradley 1395 Spare Parts include units such as discrete adapter boards, digital reference boards, multi-communication adapter boards, ControlNet adapter boards, feedback boards, node adapter boards, armature pulse boards, and PSI boards. Additionally, the 1395 Spare Parts feature power supply boards, 24 Volts transformers, fuses, pilot relays, heatsink thermoswitches, MOV fields rated at 240 to 480 Volts, 3-phase MOV fields rated at 240 to 480 Volts, and MOV control power, among others. Other items included in the 1395 Spare Parts series include screws, bus bars, washers, standoffs, left and right-hinge brackets, regenerative and non-regenerative power boards with dual field MOVs and TBIs, and 4-pin cable connectors.
