Allen Bradley
800H-PRA16
This push button is equipped with one normally open (NO) and one normally closed (NC) contact for versatile control options. It has a robust enclosure rated Type 4/4X/13, ensuring durability in challe
From $158
Available Free UPS Ground on All Parcel Orders!
+1 (919) 205-4392
Allen Bradley 800H Push Buttons
The Allen Bradley 800H push buttons are 30 mm push buttons that can be used in a wide range of industrial control applications, and they are designed to be durable. The 800H series includes push buttons with a range of colors, contact options, illumination options, and other features that users can select from. Color options for 800H push buttons include red, green, black, blue, gray, orange, and white. Some 800H Push Buttons models are available with legend caps that identify the push button and its functions. These push button models include models with green caps that have the legend "start" printed on them in white letters, and models with red caps that have the legend "stop" printed on them in white letters. Many 800H push buttons are made of durable Type 4/4X/13 plastic. Push buttons with contact configurations of 1 N.C., 1 N.O., or 1 N.C. and 1 N.O. are available in the 800H push buttons series. Some 800H push buttons are illuminated with either universal or transformer LEDs. The 800H push buttons are available with flush heads or with extended heads.
The Allen Bradley 800H push buttons can support vibration ratings of 10 to 2000 Hz and 0.06 inches of displacement/10 G peak-to-peak (except for the logic reed). The shock ratings of the 800H push buttons include 25 g for 11 ms (contact fragility) and up to 100 g with no damage. Some 800H push buttons have minimum mechanical lifespan ratings of 10,000,000 mechanical design lifecycles or actuations. Different models support different typical operating force ratings. The 800H push buttons that are non-illuminated and have no contact blocks support typical operating force ratings of 2 pounds maximum. The 800H push buttons that are illuminated have typical operating force ratings of 5 pounds maximum. The 800H push buttons typically support wires with gauges of #18 to 14 AWG, but some push buttons can support MaxDuty wire gauges of #18 to 10 AWG. These push buttons can operate at temperatures of -13 to 104 degrees Fahrenheit and be stored at temperatures of -40 to 185 degrees Fahrenheit. The components in the 800H push buttons are made of different types of plastic. The sockets, bushings, mounting rings, and non-illuminated caps are made of polyester, while the trim washers, thrust washers, and illuminated caps are made of nylon.
Learn more
Browse 800H Push Buttons
Browse available units in our catalog of 800H Push Buttons.
- Allen Bradley
800H-1HZ4R
This enclosure is rated at NEMA Type 4/4X/13, making it suitable for harsh conditions. It features a single operator opening and a conduit hub diameter of 3/4 inches. The enclosure operates in a tempe
From $87In Stock Ships Today - Allen Bradley
800H-FRXNP16GA7
Featuring a standard mushroom head design, the 800H-FRXNP16GA7 utilizes two sets of contact blocks, consisting of one normally closed latch block and one normally closed block. The button is mounted s
From $162In Stock Ships Today - Allen Bradley
800H-HP2KB6
This selector switch operates without terminal guards and utilizes a KB6 maintained cam type for its function. The knob color is a white insert, and illumination is not included in this model. It is f
AvailableCall - Allen Bradley
800H-PRBH16G
Incorporating a green lens, this push-button features an extended head design without a guard. It supports a frequency range between 50 Hz and 60 Hz and operates effectively at altitudes up to 1000 me
From $202In Stock Ships Today - Allen Bradley
800HL-JP2KB7AAXX
This selector switch provides significant functionality with a mounting size of 30 mm. The lever is gray, and it incorporates a KB7 cam type. It operates effectively in environments with a temperature
From $327In Stock Ships Today - Allen Bradley
800H-2HD
The 800H-2HD push button features modular NO/NC contact blocks in a compact design, suitable for panel openings of 30.5 mm. It operates under a single-pole, single-throw circuit type and withstands vi
From $224In Stock Ships Today - Allen Bradley
800HL-PPT16
This hazardous location pilot light supports a maximum circuit voltage of 600 V AC/DC, capable of handling thermal currents of 10 A AC and 2.5 A DC. It has a mechanical life rated for up to 200,000 op
From $130Available - Allen Bradley
800H-2JRGH91KB7AX
This selector switch has three distinct positions and accommodates contact blocks, including one normally open (N.O.) and one normally closed (N.C.) configuration. Designed for panel mounting, it util
From $206In Stock Ships Today - Allen Bradley
800H-R3HX7
Featuring a robust metal construction, this pushbutton station supports up to three circuits with both normally open and normally closed configurations. Its manual reset capability and three-position
AvailableCall
