1994 results
The IC600BF843 allows for input ranges of 0 to 10V, -10 to 10V, and 4 to 20 mA (1 to 5V). It boasts a resolution of 12 binary bits and features LED indicators for monitoring purposes. Measured accuracy for typical voltage inputs at 25 degrees Celsius is 0.025% of full scale, while the maximum voltag
The GE Fanuc Automation IC697PWR720 power supply adapter (PSA) module has a power supply of 5, 12, and -12 Volts DC and a current to rack rating of 18, 2, and 1 Amps, respectively. It supports dual-rack operations.
The GE Fanuc IC698ACC701 Auxiliary Smart Battery Module is made for the Rx7i PACSystem series. This battery module provides extended RAM backup for RX7i CPUs. This module has 15 Amps of maximum battery capacity and a standard battery life of 200 days.
This discrete input module supports 16 channels and accepts an input voltage range between 10.2 to 28.8V DC. It has a typical filtering time of 1.5 ms and operates under negative logic, making it suitable for specific applications. The module's input impedance is roughly 5.1 kilohms, and it can hand
The GE Fanuc IC698CMX016 Control Memory Xchange Module is a module for the Rx7i PACSystem. This CMX module is software-configurable, and it supports network-compatible VMIC 5565 reflective memory devices.
The IC610MDL107 input module is designed with 16 sink input points, operating at a voltage rating of 24V DC. It features removable terminal blocks for easy installation and maintenance, and each input point includes its dedicated LED indicator. This module has a maximum open circuit voltage of 36V D
The GE Fanuc IC694MDL330 module is an output module that can be installed in any I/O slot in the RX3i PLC system. The module has a rated voltage of 120 to 240 Volts AC and a current output of 2 Amps.
This output module operates within a 5 to 24 VDC voltage range, with a peak voltage capability of 40 VDC. The removable terminal block simplifies installation and maintenance. The typical on-state voltage drop is 1 Volt DC, rising to a maximum of 2 Volts DC at full load. The leakage current is measu
The IC693TCM302 temperature control module that is manufactured by GE Fanuc is part of Series 90-30. The IC693TCM302 module is a thermocouple input module and it has an output voltage range of 18 to 30 Volts DC. The unit has a load current of 100 milliAmps and a maximum off-state leakage of 0.1 mill
This output module features two groups, each containing four output points. Rated at 115 volts AC, it supports TRIAC switching. This device operates effectively in a temperature range of 0 to 60 degrees Celsius and allows for an inrush current of up to 12 amps for 33 milliseconds.
The GE Fanuc Emerson ST-3702 RTD input module consists of two input channels. It supports diverse RTD input configurations, enabling use with numerous sensor types. The device allows for a diagnostic open-channel option and features a resolution of 0.1 degrees Celsius at specific sensor resistance s
The GE Fanuc IC693MDL230 isolated input module is manufactured by GE Intelligent Platforms/GE Fanuc as a member of the Series 90-30 product family. It operates on 120 Volts AC voltage and it is intended for use with the Series 90-30 Programmable Logic Controller (PLC) system.
