The Allen-Bradley 1336 PCB boards make up the family of PCB board spare parts for the Allen-Bradley 1336 PLUS, 1336 PLUS II, 1336 FORCE, 1336 IMPACT, and 1336 REGEN drive families. Spare PCB boards in this family include the main control board PCB for the Allen-Bradley 1336 PLUS, 1336 PLUS II, 1336 FORCE, and 1336 IMPACT drives with firmware versions 2.03 to 4.03, the main adapter board PCBs, the gate drive board PCBs (with or without a conformal coating), the precharge PCBs, and the snubber PCBs. The Allen-Bradley 1336 PCB boards provide excellent and easy to install PCB board spare part options for all the Allen-Bradley 1336 drive families. The wide range of available options makes them ideal spare part accessories for installation, integration, and maintenance.
Another unique property of the 1336 PCB board spare parts is that they can be used and installed in multiple drive models. There are PCB board options for every 1336 PLUS, PLUS II, FORCE, IMPACT, and REGEN drives with voltage ratings from 200 to 600 Volts AC and 1 to 600 Horsepower output. The 1336 PCB boards spare are also available for IP 00 (Open), IP 54 (NEMA 12), and IP 65 (NEMA 4) PLUS, PLUS II, FORCE, IMPACT, and REGEN rated drives. Testing and installing the 1336 PCB boards is easy with the user manuals that are available on the Allen Bradley/Rockwell Automation website. Like all 1336 drives and accessories, the 1336 PCB boards have a rated operating temperature range of 0 to 40 degrees Celsius (NEMA 4 and 12 rated boards) and 0 to 50 degrees Celsius (NEMA Open rated boards).
Browse available units in our catalog of 1336 PCB Boards.
This gate drive printed circuit board is oriented for vertical installation and incorporates dynamic braking as its braking method. It emphasizes power conversion through inverter switching and featur
This PCB operates at 230 volts AC and supports an auxiliary supply input of 24 VDC. It features six jumper connectors for versatility and allows for high-voltage auxiliary input. The isolation functio
This gate drive board is designed for use with frame sizes A, B, C, D, or E, accommodating multiple systems. It also functions within a voltage class of 460 Volts AC and maintains operational performa
This replacement circuit board operates at a rated DC bus voltage of 575 volts and is standoff-mounted, allowing for secure installation. Designed with ESD sensitivity in mind, it features stab-on ter
This board is classified as a major drive assembly and supports level shifting functionality. It employs an open style PCB design and is compatible with IGBT switching devices. The mounting is straigh
Designed for operation within a temperature range of 0°C to 50°C, this gate drive board also maintains functionality at altitudes of up to 1000 meters without derating. It supports both 50 Hz and 60 H
Operating within a frequency range of 50 Hz to 60 Hz, this precharge board is designed for use with 3-phase systems. It also includes connectivity options through J1, J2, and J3 connectors with a TB1
This internal mounting drive board is constructed for use with Allen Bradley's 1336 series drives. It operates effectively in a temperature range from 0 to 55 ⁰C and maintains performance under relati
Designed for compatibility with IGBT switching devices, this board has an internal mount style and a rated motor power capacity of 60 HP. It features an open style PCB configuration and utilizes low-l
This internal PCB device operates within a voltage range of 500 to 600 VAC and provides a three-phase output. It is compatible with Plus, Plus II, Force, and Impact drives, supporting adjustable frequ
