The Allen-Bradley 1336 PCB boards make up the family of PCB board spare parts for the Allen-Bradley 1336 PLUS, 1336 PLUS II, 1336 FORCE, 1336 IMPACT, and 1336 REGEN drive families. Spare PCB boards in this family include the main control board PCB for the Allen-Bradley 1336 PLUS, 1336 PLUS II, 1336 FORCE, and 1336 IMPACT drives with firmware versions 2.03 to 4.03, the main adapter board PCBs, the gate drive board PCBs (with or without a conformal coating), the precharge PCBs, and the snubber PCBs. The Allen-Bradley 1336 PCB boards provide excellent and easy to install PCB board spare part options for all the Allen-Bradley 1336 drive families. The wide range of available options makes them ideal spare part accessories for installation, integration, and maintenance.
Another unique property of the 1336 PCB board spare parts is that they can be used and installed in multiple drive models. There are PCB board options for every 1336 PLUS, PLUS II, FORCE, IMPACT, and REGEN drives with voltage ratings from 200 to 600 Volts AC and 1 to 600 Horsepower output. The 1336 PCB boards spare are also available for IP 00 (Open), IP 54 (NEMA 12), and IP 65 (NEMA 4) PLUS, PLUS II, FORCE, IMPACT, and REGEN rated drives. Testing and installing the 1336 PCB boards is easy with the user manuals that are available on the Allen Bradley/Rockwell Automation website. Like all 1336 drives and accessories, the 1336 PCB boards have a rated operating temperature range of 0 to 40 degrees Celsius (NEMA 4 and 12 rated boards) and 0 to 50 degrees Celsius (NEMA Open rated boards).
Browse available units in our catalog of 1336 PCB Boards.
This gate driver board functions effectively within the parameters of frame size C and requires one board per drive for optimal performance. It features an operating temperature range from 32 to 104 d
This PCB gate drive board is compatible with 1336 PLUS, PLUS II, FORCE, IMPACT, and REGEN drives. It operates effectively within a temperature range from 0 °C to 50 °C and supports storage temperature
This gate driver PCB is compatible with a range of drives, including 1336 PLUS, 1336 FORCE, and 1336 IMPACT models from Series C and above, as well as Series A and above for the 1336 PLUS II. It opera
Designed for use with 1336 PLUS, PLUS II, FORCE, IMPACT, and REGEN drives, this board operates efficiently within a temperature range of 0 °C to 50 °C. It can be stored in conditions as low as -40 °C
This gate driver board operates efficiently with an AC voltage rating of 575 V and supports drive power up to 350 HP. Designed for mixed and digital control signals, it includes passive cooling and is
This board features high-power gate drive circuitry and supports an output signal frequency of 50 kHz. Rated for continuous load at 10 A and a peak load of 20 A, it also incorporates MODBUS RTU commun
This gate drive board requires a single unit for each applicable drive, which includes models like the 1336 PLUS, PLUS II, FORCE, IMPACT, and REGEN. It functions effectively in a 3-phase configuration
Designed to be compatible with Frame D size installations, this inverter snubber board includes three boards and 15 fastening screws. It operates within a temperature range of 0°C to 50°C and can be i
This precharge PCB is compatible with multiple frame sizes, specifically sizes C through H. It is utilized in conjunction with several drive types, including 1336 PLUS, PLUS II, FORCE, IMPACT, and REG
Designed for 300 horsepower applications, this gate drive board uses a frame size classified as F. It requires only one board per drive and can be mounted in a plate configuration. Rated for use at al
