The 1336 PLUS II drive series by Allen-Bradley is a series of compact and high-performance adjustable frequency AC drives with sensorless vector control that is designed to provide speed control solutions to a wide range of applications. The 1336 PLUS II drives offer common designs, control interface options, and device communication options that are found across the entire series which makes integration, installation, operator training, and maintenance simple. The 1336 PLUS II drives are available in ratings from 0.37 to 448 kiloWatts (0.5 to 600 Horsepower) with voltage ranges from 200 to 240 Volts AC, 380 to 480 Volts AC, and 500 to 600 Volts AC. They are available in 9 different frames (A1, A2, A3, A4, B1, B2, C, D, and E), and they have constant torque and variable torque capabilities. The 1336 PLUS II drives use programmable pulse width modulation frequency with adjustable output voltage for exceptional speed and torque control, and these outputs can be easily fine-tuned to provide the desired performance under varying loads.
The 1336 PLUS II drives have built-in fault detection and overload protection, and they also have real-time preventive and fault reporting capabilities that alert operators to any faults through alarms and plain text diagnostic messages for quick corrective measures. The 1336 PLUS II drives offer the users motor control with the standard Volts per Hertz control (with a customizable Volts per Hertz curve) and the sensorless vector control (SVC) which provide outstanding speed and torque performance, and a higher starting torque of up to 250%. The 1336 PLUS II drives have configurable I/O interfaces, optional human-machine interface modules, Remote I/O, RS-232/422, DeviceNet, and Enhanced DeviceNet modules, control interface modules (with and without encoder interfaces), and multiple language options. The 1336 PLUS II drives are available in IP 00 (Open), IP 20 (NEMA Type 1), or IP 54 (NEMA Type 12) installations, and they are CE, CSA, UL, C-TICK certified.
Browse available units in our catalog of 1336 PLUS II Drives.
This adjustable frequency drive offers extensive operational flexibility, supporting an operating temperature range from 0 to 40 °C and storage conditions from -40 to 70 °C. With TTL contact control i
Part of the 1336 PLUS II Drives series, this adjustable frequency AC drive is rated for operation between 380 VAC and 480 VAC. It provides an IP20 rated NEMA 1 enclosure. This drive operates effective
Designed for adaptability, this drive supports storage temperatures from -40 to 70 degrees Celsius and operates efficiently within 0 to 50 degrees Celsius. It is classified with an IP00 enclosure type
This AC drive features an enclosure rated at NEMA 1 with IP20 protection. It can operate within a temperature range from 0 °C to 40 °C. Storage conditions should be maintained between -40 °C and 70 °C
The Allen Bradley/Rockwell Automation 1336F-A007-AE-FR French-language adjustable frequency drive can provide an operating efficiency rating of up to 97.5 percent as long as the environment complies w
Designed for both constant and variable torque applications, this model features a consistent input current of 25A and an output current of 24A. It has a kVA rating ranging from 21 to 26 kVA for input
This device is rated for a horsepower of 10 HP (7.5 kW) and operates with a nominal bus voltage of 324 Volts DC. It supports a frequency tolerance between 47 and 63 Hertz, facilitating a stable perfor
The Allen Bradley 1336F-B015-AA-EN-GM1-HASP-L6 adjustable frequency drive is a 1336 PLUS II series AC drive. It can operate at 380 to 480 Volts AC input voltage. The nominal output power rating of the
This control interface board operates effectively within a temperature range from 0°C to 50°C. It can endure storage conditions between -40°C and 85°C, making it suitable for various environments. The
This drive features an IP 20 enclosure type and supports ambient conditions with relative humidity ranging from 5 to 95% without condensation. It can endure line transients of up to 6000 volts peak an
