The 1336 Drives are microprocessor controlled, high performance, adjustable frequency drive which are designed to be used to control three phase induction motors for critical industrial applications. The drive also produces a three phase, PWM, adjustable frequency output to supply an adjustable motor speed. These drives output voltage is a function of output frequency and is adjustable to match motor parameters to obtain the optimum motor performance.
Browse available units in our catalog of 1336 Adjustable.
This dynamic brake chopper features a rated DC voltage of 750 V and has a dynamic braking resistor value of 2.5 ohms. The chopper includes IGBT transistors and is enclosed in an open-style design with
Designed for internal mounting, this communication board utilizes an SCANport for connection and includes a 14-pin connector for the SCANport and a 3-pin connector for Remote I/O. The device operates
The Allen Bradley 1201-HAS2 plug-in human-machine interface module consists of a programmer and controller module with a physical keyboard.
This braking module outputs up to 750 watts and operates efficiently across 50 to 60 Hertz system frequencies. With a maximum initial contact resistance of 50 milliohms, it supports an altitude withou
The 1201-HAP is a human-machine interface module with the programmer-only function. It has been manufactured and designed by Allen Bradley-Rockwell Automation. This module comes designed with a NEMA T
This fan is specifically for Frame F drive enclosures and mounts directly on the side of the drive heatsink. It operates within a temperature range of 0 to 40 degrees Celsius and can be installed at a
This communication module supports data rates of 125, 250, and 500 kbps. It includes both a 5-pin DeviceNet connector and a 14-pin SCANport connector. ESD protection measures are rated at 4 kV contact
This drive programming terminal operates on a power supply input of 5 VDC and requires a current input of 160 mA. It has a single SCANport for connectivity. The device is housed in a NEMA Type 1 enclo
The Allen Bradley 1201-HAS1 programmer and controller module with an analog pot consists of a snap-in loose kit that can be installed onto any compatible AC drive.
The 1336 Adjustable series is a series of drives manufactured by Allen-Bradley. The 1336 Adjustable drives are microprocessor-controlled drives that are known to produce the high-level performance that is required for controlling the 3-phase induction motors. The 1336 Adjustable drives are critical for various industrial applications. The 1336 Adjustable drives produce the 3-phase PWM adjustable frequency output for supplying adjustable motor speed. The output of the 1336 Adjustable drives is a function of the output frequency and it is usually adjustable to ensure an exact match to the motor parameters. The 1336 Adjustable drives have been designed as constant torque, adjustable speed control drives and they come with 150% overload capability. The drives under the 1336 Adjustable drives series are adaptable through programming to handle a wide variety of applications.
The 1336 Adjustable series drives feature units that are specially designed to produce an exceptional output voltage with the current waveform. Before deploying the unit with an inverter, notice any special considerations that may be present in the installation area. Note that slow speeds might result in problems related to cooling due to the reduction in the fan rotation speed. The 1336 Adjustable drives could overheat if they are operated at a highly rated torque for long periods. The 1336 Adjustable drives come equipped with the MOV or the Metal Oxide Varistor, providing voltage surge protection. The MOV circuit is also designed for surge suppression only and not for continuous operation. The 1336 Adjustable drives support user parameters for selecting and controlling the operations of the drives. To ensure optimal performance, make sure that the whole system is correctly applied or installed.
