The Allen-Bradley 1336 PLUS drives are a family of microprocessor-based AC drives with sensorless vector control that are designed to provide control for 3-phase motors in critical applications where accurate torque and speed control is necessary. The 1336 PLUS drive series offers easy-to-use and cost-effective motor control solutions to applications with even the tightest speed requirements, and they come with built-in protection features that help to improve performance and save maintenance costs caused by unscheduled downtimes. The 1336 PLUS drives have A1, A2, A3, A4, B1/B2, C, D, E, G, and G frames with input ratings from 200 to 600 Volts AC and 0.37 to 448 kilowatts (0.5 to 600 Horsepower). All 1336 PLUS drives have both variable and constant torque capability, and each drive is sized to 115% of the full load Amps for variable torque applications, and 150% of the full load Amps for constant torque applications.
The 1336 PLUS drives employ the Pulse Width Modulation (PWM) control with programmable carrier frequencies from 2 to 10 KiloHertz. Depending on the application type, the operators can choose between the standard Volts per Hertz control method, which offers customizable Volts per Hertz curve and it is suitable for centrifugal and HVAC applications, and the sensorless vector control (SVC), which provides tighter speed control even under varying loads, higher starting torque, and lower speed operation than other control methods. The 1336 PLUS drives offer easy-to-use human-machine interface module options, communication options (single-point remote I/O, RS-232/422, DF1, DH-485, and DeviceNet networks), and the control interface card option with or without an encoder interface. This drive series features easy-to-read display interface options that support multiple languages for easy configuration, diagnostics, and troubleshooting processes. The 1336 PLUS drive series features drives with IP 00 (Open), IP 20, IP 54, and IP 65 enclosures, and they have a non-derating operating temperature range of 0 to 40 degrees Celsius.
Browse available units in our catalog of 1336 PLUS Drives.
This model features IP20 protection and is housed in a NEMA 1 enclosure. Operating temperatures for this unit range from 0 °C to 40 °C, allowing for optimal functionality. It also has storage capabili
This adjustable frequency AC drive operates efficiently at rated voltages of 380 to 480 volts. It has a horsepower rating of 7.5, an open type enclosure, and compatibility with TTL contact control int
This drive operates within a voltage range of 380 to 480 VAC and has a power output rating of 7.5 kW. It is equipped with an IP20 protection rating and meets NEMA 1 enclosure standards. The device sup
This drive is rated for an input voltage range of 380-480V AC and can output voltage from 0 volts up to the rated voltage. It is capable of delivering 10 horsepower and has an IP20 enclosure for prote
This drive supports voltage ratings from 380 to 480 volts AC and has a nominal horsepower rating of 10 HP. It incorporates a robust user interface through a programmer/controller HMI module and a digi
This AC drive supports both variable and constant torque applications. It has an input current rating of 22 amperes for variable torque and 17 amperes for constant torque. The overall input kVA for va
Operating at a range of 380 to 480 volts AC, the 1336S-B015-AA-EN5 AC drive supports a power capacity of 15 Hp. With a NEMA 1 enclosure and rated IP20, it is appropriate for standard operational envir
Operating with a nominal bus voltage of 648V DC, this unit features an enclosure rated at IP20. A user-friendly programmer-only interface is included, along with a 115V AC control interface. Sensorles
This drive provides an output frequency range from 0 to 400 Hz and features varying output currents of 8.4 Amps for constant torque and 9.0 Amps for variable torque applications. The device supports b
With a nominal horsepower rating of 7.5 HP (5.5 kilowatts), this drive operates on a three-phase system. The output frequency can be adjusted from 0 to 400 Hertz, and it supports intermittent overload
