The Allen-Bradley PowerFlex 523 AC drives are designed for motor control applications requiring up to 22 kilowatts and 30 Horsepower of output. The Allen-Bradley PowerFlex 523 drives are ideally suited for standalone machines. The PowerFlex 523 AC drives are optimized for use in shared DC bus and common DC bus installations. The 3-phase input on the PowerFlex 523 drives provides a full rating whereas the single-phase input derates the output to a 35% rating. The available power output ratings range from 0.2 to 22 kilowatts (0.25 to 30 Horsepower). The PowerFlex 523 drives support global voltage classes of 100 to 600 Volts AC. The input frequency tolerance is from 47 to 63 Hertz. The control options provided on PowerFlex 523 drives include sensorless vector control and Volts per Hertz control. The PointStop drive feature allows the users to stop the motor load in a consistent position without encoder feedback. The PowerFlex 523 drives support 1 PID loop for enhanced application flexibility.
The I/O available on the PowerFlex 523 drive includes 1 analog input, 5 digital inputs, 1 analog output, and 1 relay output. The RS-495/DSI interface enables PowerFlex 523 drives to be used in a multi-drop configuration. The optional communications kits are available for the ProfiBus and DeviceNet networks. The PowerFlex 523 drives support USB programming by using either the Connected Components Workbench or Studio 5000 Logix Designer software. Without derating, the PowerFlex 523 drives can support an air temperature between -4 and 122 degrees Fahrenheit. With derating, these drives can support -4 to 140 degrees Fahrenheit or -4 to 158 degrees Fahrenheit with an optional control module fan. The drives can be mounted side-by-side with only a 1.96-inch airflow gap at the top and bottom of the drive.
Browse available units in our catalog of PowerFlex 523.
Engineered with an open-type enclosure, this drive has an output current rating of 24.0 A and is housed in Frame D. It maintains an IP20 rating, ensuring it is protected from solid objects larger than
Allen Bradley PowerFlex 523 AC Drive has One Phase, 240 VAC voltage and 4.8 Amperes Output
Allen Bradley PowerFlex 523 AC Drive has Three Phase, 240 VAC voltage and 5.0 Amperes Output
This model operates with an output current of 8.0 Amps and features a frame size classified as Frame A. The drive is designed for use at input frequencies from 50 Hz to 60 Hz, making it adaptable for
Allen Bradley PowerFlex 523 AC Drive has Three Phase, 240 VAC voltage and 17.5 Amperes Output
Allen Bradley PowerFlex 523 AC Drive has Three Phase, 480 VAC voltage and 37 Amperes Output
Allen Bradley PowerFlex 523 AC Drive has Three Phase, 600 VAC voltage and 6 Amperes Output
This drive accommodates a minimum input frequency of 50 Hz and a maximum input frequency of 60 Hz. Crafted in an E Frame size, it has an IP20 rating, suitable for open-type environments. It can handle
This device supports a wide input frequency range from 47 to 63 Hz and provides a control method based on volts/hertz. With an overload capability of 110% for one minute, it is designed for dynamic ap
Allen Bradley PowerFlex 523 AC Drive has Three Phase, 480 VAC voltage and 2.3 Amperes Output
