Choosing the Right Mitsubishi Melservo Drive: A Comprehensive Guide

High performance in industrial activities requires the selection of the proper industrial drive. This article serves as a family guide for navigating the diverse landscape of Mitsubishi Melservo drives. Choosing the best industrial drive is essential for optimizing performance, reliability, and efficiency in today’s demanding industrial setting. This extensive guide seeks to provide professionals with sufficient modules and their corresponding information so they may make decisions that are particular to their needs. We will discuss some of the modules’ respective features, such as operating frequency, output voltage and current, working temperature, power deliverance, protection rating, weight, and measurement.

MR-J2-100B:

The Mitsubishi Melservo series’ MR-J2-100B servo drive provides efficient control towards different servo motors in various industrial settings and applications. The frequency rating of 50/60Hz and Three-phase 200-230Volts-AC guarantees nominal energy supply to the associated motor system. The drive is protected against any power abnormalities by its ability to withstand voltage changes within a 3-phase 170 to 253VAC range. The MR-J2-100B uses a complex control system that includes current control and sine-wave PWM control to guarantee precise motion control and smooth operations. Its integrated dynamic brake improves operating safety by enabling quick deceleration. The drive reduces energy loss during operations because of its 80% inverted efficiency rating. Its 20W resistor power and 18J capacitor charging capacity allow precision motor control and fast reaction times. The MR-J2-100B is a force-cooling device with an open construction (IP00) that efficiently distributes heat and shields against environmental pollutants. It exhibits resistance in different industrial applications, operating under ambient temperatures from 0-55 degrees Celsius (32 to 131°F). This servo drive offers dependable operation in tough industrial conditions with its resistance to vibrations up to 5.9 [m/s2] or 19.4 [ft/s2] and its ambient humidity tolerance of 90%RH or less (non-condensing). It weighs about 1.7 kg (3.75 lbs).

MR-JE-40A:

This module has an output power of 0.4 kW, operates as a servo drive, and meets modest power needs. The General Pulse Interface emphasizes its adaptability and interoperability with different control systems. This drive can be utilized in different settings since it can be incorporated into single-phase power networks and works on a 1-phase power standard at 200 to 240 Volts Alternating Current. It allows control over a single axis. With a 2.8 amp rated current and integrated safety and energy-saving features, including a regenerative resistor and dynamic brake, the amplifier improves both performance and safety while in use. The RS-422 and RS-485 protocols make it easier to communicate with external systems. This drive offers endurance against solid objects with its IP20 degree of protection. It is also certified by the UKCA and CE, proving that it aligns with health and safety needs. These features depict that this module is ideal for use in different automation environments.

MR-J4-100A-RJ:

 The MR-J4-100A-RJ servo drive has technological specs designed to provide accurate servo motor control in industrial settings. The output rated voltage of 170 V AC in three phases and the rated current of 6.0 A ensure that the motor operates efficiently. To ensure compatibility with typical power systems, the main circuit’s supply can handle a 3-phase 200-240 V Alternating Current, 50 Hz/60 Hz input working frequency with a rated current of 5.0 A. It provides dependable control signal processing by supporting single-phase 200V-240V AC, 50 Hz or 60 Hz working frequency, with a rated current of 0.2 A, for the power supply input of the control circuit. The drive performs energy-efficiently, using just 30 W of electricity when in operation. It guarantees precise and seamless motor control by using a sine wave Pulse Width Modulation technique. Its integrated dynamic brake allows for quick deceleration for increased safety. To further ensure operating safety and lifespan, the drive also has preventive features such as overload shut-off (electronic thermal), regenerative overvoltage shut-off, overcurrent shut-off, and servo motor overheat protection.

MR-J3-100BS:

The Mitsubishi Melservo Drives line includes the MR-J3-100BS servo drive, which operates on a three-phase supply voltage between 200 and 230V AC, having a working frequency of 50/60 Hertz. This module delivers an output power capacity of 1.1 kilowatts at maximum working functionality. Various control techniques are available to meet motor control needs, such as speed or current control. Control modes include torque, speed, and position control, allowing for a variety of motor control tactics. Encoders, which come in incremental and absolute versions, provide motor feedback, guaranteeing exact feedback for precise control. SSCNET III/H, an Omron-developed proprietary network, is included in communication interfaces, allowing easy integration into pre-existing industrial networks. Protection against overload, overvoltage, overcurrent, overspeed, and sudden power loss are built-in safety features that guarantee equipment protection and operating safety. This module has a working temperature range of 0°Celsius to 55°Celsius, which helps this device to function dependably in a variety of environmental settings. The MR-J3-100BS, weighing 3.1 pounds (1.4 kilograms), is lightweight and portable for servo motor control applications.

 MR-J3-500B:

Under the Mitsubishi Melservo Drives range, the MR-J3-500B is an AC Servo Motor Drive that runs on a 3-phase power supply voltage between 200 and 230VAC at 50/60Hz. It accepts voltage variations that are allowed between 170 and 253 VAC in three phases. Furthermore, it has a 24 VDC voltage with a 10% tolerance. The drive is compatible with a current control system and sine-wave PWM control. Its 4.6-kilogram weight, or 6 pounds, makes it a practical and small form factor for incorporation into industrial systems. With measurements of 25 cm in height, 13 cm in width, and 13.2 cm in length, it offers a rather compact installation footprint. Support for real-time auto-tuning enables precise and effective motor control. Together, these features place the MR-J3-500B in an advantageous position for applications needing accurate control over AC servo motors, providing performance and dependability in industrial environments.

HA-FF63:

The HA-FF63 module functions as both a motor and a servo amplifier. Because of its rated output capacity, which ranges from 0.1 kW to 0.75 kW, it can meet a variety of power needs in industrial automation systems. This module has a maximum spinning speed of 4000 revolutions/min and a rated rotating speed of 401828 revolutions/min. Its 30.1 kW/s power rate highlights how well it can manage changes in dynamic load. It provides enough power at a rated current of 3.6 A while preserving the stability of operation. The module weighs around 4.8 kg, and therefore, it is a manageable and sturdy device that makes installation and transit simple. It can respond to control inputs quickly because of its 2.1 kHz speed response frequency, which guarantees precise motor placement and speed regulation. With its generic pulse interface type for communication and three-phase AC 200V power requirements, it can be used with most industrial power systems and control protocols. Adhering to UL/cUL regulations, the HA-FF63 places a premium on dependability and safety, making it a top option for servo motor applications in various industrial domains.

MR-J2-40D-S28-P01:

The MR-J2-40D-S28-P01 drive from the Mitsubishi Melservo Drives family has a supply voltage between 200-230V Alternating Current and a 400W power rating. The maximum speed is 3000 rpm. It uses an absolute encoder for feedback. A 24V DC signal indicates that the servo drive is on. The drive has overload protection to defend against extreme loads. An RS-485 interface facilitates communication with external systems. The dimensions of the MR-J2-40D-S28-P01 are 40mm wide, 150mm in height, and 130mm in depth. These technological details establish the MR-J2-40D-S28-P01 as a dependable and adaptable part for accurate servo motor control applications, providing precision and efficiency in industrial automation settings.

MR-J4-500A:

The MR-J4-500A is a three-phase AC servo drive with a 200V class supply voltage range of 200Vac-240Vac intended for industrial use. It produces 5000W (5kW) of rated active power with a rated current of 28 amps. The input current used by the drive is 21.7A. The RS-422 and RS-485 protocols make communication easier and guarantee interoperability with industrial communication systems. It protects against solid objects as it is kept in a casing with an Ip20 rating. Forced ventilation provides cooling, guaranteeing ideal operating temperatures for dependable operation. These features make this drive a good option for use in industrial automation.

MR-J3-10BS:

The Mitsubishi Melservo Drives series includes the MR-J3-10BS, which is highly significant in the industry. For this module, the SSCNET network is supported, and it works with motors such as the Melservo HF series motors. It has a working frequency of 50 to 60 Hertz and allowable voltage variations in the 170-254 volts Alternating Current range. With a 10% tolerance and a 24-volt Direct Current output voltage, the drive may be wired up to 50 meters apart, providing around 100W at output. A current control system and sine-wave PWM control enable control. Measuring 6 x 4 × 7 inches, it has three connections and several ports for connectivity. CN2 is the motor connection that is in use. With a weight of about 0.8 kg, the MR-J3-10BS offers lightweight and small servo motor operating solutions in different industrial automation jobs that demand precise and dependable motor control.

MR-J2-60CT:

The Mitsubishi Melservo Drives series includes the MR-J2-60CT servo drive, which is distinguished by a set of technical parameters. This module has a rated current of 3.2 Amps along with a rated power of 0.6 kWatt. Operating between 200 and 230 VACs guarantees interoperability with most electrical systems. The drive is fitted with a K5 fuse type with a fuse voltage (UL) of 250VAC and a fuse current (UL) of 20A. These features improve safety by preventing electrical failures. The 10W integrated regenerative capacity of the MR-J2-60CT allows for energy recovery during operation, maximizing total energy efficiency. It can also handle a 50A rush current, which makes it easier to start up and run when there are abrupt changes in load. Its 1-kilogram weight makes it a lightweight, compact device that may be easily integrated into various automation configurations. Considering all the above features, the MR-J2-60CT is a dependable servo drive option that offers accurate control over motor systems while upholding safety regulations and maximizing energy efficiency. Because of its technological characteristics, it can be used in industrial settings where steady and effective servo motor control is necessary.

MR-JE-200A:

The Mitsubishi Melservo Drives series includes the MR-JE-200A, a servo drive mostly used for servo motor control applications. Having 10.5 Amps of rated current, it can accommodate both 3-phase and 1-phase systems and works within the 200–240V AC power supply voltage range. With its USB connector and compatibility with RS-422/RS-485 communication protocols, the amplifier makes it easy to connect to other systems and equipment. Precise motor control is ensured by the combination of the current control technique and sine-wave PWM control. It also has an integrated dynamic brake for increased operating safety. Its IP20 protection rating shows that it can resist solid objects and has a small form factor (height 168 x width 90 x depth 195 mm) that helps in industrial installations. The MR-JE-200A operates at an optimum working temperature between 0 and 55 degrees Celsius and exhibits stability in different working conditions.

MR-J4-10A:

The Mitsubishi Melservo Drives include the MR-J4-10A servo drive, designed to provide industrial applications with precise control over servo motors. It guarantees effective motor running with a three-phase output rated voltage of 170 V AC. This module has a rated current of 1.1 amps. Main circuit power supply compatibility is ensured by the voltage/frequency range of 3-phase or 1-phase 200 V AC to 240 V AC, 50 Hz/60 Hz. The MR-J4-10A ensures precise motor control and optimal performance using current and sine-wave PWM control. When required, its integrated dynamic brake allows for quick deceleration, improving operating safety. Furthermore, incorporating connection features like USB and RS-422 enables a smooth interface with other systems and devices. Moreover, the amplifier has two analog monitoring channels, enabling accurate tracking and modification of motor performance.

Conclusion

In conclusion, a wide variety of servo amplifiers and drives are available in this Mitsubishi Melservo Drives guide, each specifically engineered to fulfill unique demands in industrial automation. A range of technical specifications are available for these devices, which include the MR-J2-100B, MR-JE-40A, MR-J4-100A-RJ, MR-J3-100BS, MR-J3-500B, HA-FF63, MR-J2-40D-S28-P01, MR-J4-500A, MR-J3-10BS, MR-J2-60CT, and MR-JE-200A. For example, the MR-J2-100B is appropriate for industrial situations with high motion control needs because of its sophisticated control system and integrated dynamic brake, which provide accurate motion control. The MR-JE-40A provides flexibility and interoperability due to its incorporated safety measures, compatibility with a range of control systems, and communication protocols. Furthermore, the MR-J4-100A-RJ and MR-J3-100BS offer precise servo motor control due to their sturdy design and support for various motor control modes. In contrast, the MR-J3-500B is appropriate for its broad range of power systems and control protocols. Furthermore, the HA-FF63 has superior power management skills and complies with safety regulations, making it a dependable choice for servo motor uses. Meanwhile, the MR-J4-500A and MR-J2-40D-S28-P01 provide dependable and accurate motor control, guaranteeing seamless operation in industrial automation settings. The MR-J3-10BS and MR-J2-60CT also provide lightweight, compact solutions for servo motor control applications, along with cutting-edge capabilities like energy-efficient operation and real-time auto-tuning. Considering all the above drives, the Mitsubishi Melservo Drives series includes many servo amplifiers and drives that meet the various demands of industries and automation.
